As the name implies, these models are built for contractors and large scale farmers who need a large powerful 20hp engine. The 20hp engine is capable of dealing with the range of oil flows and pressures required by the big round and square wrappers on the market today.
The large oil reservoir keeps working temperatures low even during prolonged, continuous wrapping cycles. May be mounted onto the wrapper or transported separately. Variable speed kits and stand alone models are available.
|
|
Contractor PowerWrap PW208 units are available to fit:
McHale 995TSR, 991TBER, 991BER
PW208Ku to fit:
Kuhn 1600/1604
PW208T to fit:
Tanco A100EH
McHale HS2000 - option model PW258 with 25hp engine and larger hydraulic oil tank.
PW258 recommended for Tanco 1814.
Stand alone units
For those wanting a totally stand alone model, we offer our units mounted on their own tough steel base.Simply pick-up using fork lift, drive it into position, place down and attach the hydraulics.
This system is available for all our models. Please call to discuss.
Variable speed kits
Variable speed kits are available as an option to enable the wrapper to run at lower speeds to cope with mishapen and awkward bales.
Click here to return to product range page
|
|
| CONTRACTOR |
TECHNICAL SPECIFICATION |
| Engine: |
20Hp twin cylinder air cooled Lombardini diesel |
| Starting: |
Electric start |
| Fuel Tank: |
16 litres |
| Engine Filters: |
Spin on fuel and oil. Oil bath air cleaner |
| Hydraulic oil filters: |
Suction and return |
| Hydraulic Oil: |
ISO 46 50 litres |
| Oil Flow: |
18 to 35 litres/min |
| Oil Pressure: |
Up to 180 bar |
| Electrical Output: |
12 amps 12 volts |
| Dimensions : |
Length: 800mm
Width: 600mm
Height:850mm
|
| Protection: |
Pressure release valve for hydraulics.
Return oil filter warning gauge |
| Warranty: |
12 months parts and labour (subject to standard conditions of business) |
|
